Reconfigurable Rainbow PIV for 3D Flow Measurement

Abstract

In recent years, 3D Particle Imaging Velocimetry (PIV) has become more and more attractive due to its ability to fully characterize various fluid flows. However, 3D fluid capture and velocity field reconstruction remain a challenging problem. A recent rainbow PIV system encodes depth into color and successfully recovers 3D particle trajectories, but it also suffers from a limited and fixed volume size, as well as a relatively low light efficiency. In this paper, we propose a reconfigurable rainbow PIV system that extends the volume size to a considerable range. We introduce a parallel double-grating system to improve the light efficiency for scalable rainbow generation. A varifocal encoded diffractive lens is designed to accommodate the size of the rainbow illumination, ranging from 15 mm to 50 mm. We also propose a truncated consensus ADMM algorithm to efficiently reconstruct particle locations. Our algorithm is 5x faster compared to the state-of-the-art. The reconstruction quality is also improved significantly for a series of density levels. Our method is demonstrated by both simulation and experimental results.

Publication
IEEE International Conference on Computational Photography (ICCP)

Citation

@inproceedings{xiong2018reconfigurable,
  title={Reconfigurable rainbow PIV for 3D flow measurement},
  author={Xiong, Jinhui and Fu, Qiang and Idoughi, Ramzi and Heidrich, Wolfgang},
  booktitle={2018 IEEE International Conference on Computational Photography (ICCP)},
  pages={1--9},
  year={2018},
  organization={IEEE}
}

All images are © IEEE 2018, reproduced here by permission of IEEE for your personal use. Not for redistribution.
